BDCOM S5612-2AC

Суммарная пропускная способность

240Gbps

Скорость обслуживания пакетов

180Mpps

Количество МАС адресов

32k

Порты

12 10G/gigabit auto-adaptation SFP+ port, 8 gigabit RJ45 TX ports, key Reset

Размеры

442.5×315×44

Источник питания

AC: 100V-240V, 50Hz±10%

DC: -36V~-72V

Рабочая среда

Рабочая температура \влажность : 0℃-50℃, 10%-90% без конденсации

температура хранения \влажность: -20℃-70℃; 5%-95%  конденсации

MAC switching function

Static configuration and dynamically learning of MAC address

Check and delete MAC address

Configuring of MAC address aging time

Limit on MAC address learning number

MAC address filtering function

Black-hole MAC items

VLAN

4K VLAN entries

GVRP

1:1 and N:1 VLAN Mapping

QinQ and selective QinQ

Private VLAN

STP

802.1D (STP), 802.1W (RSTP), 802.1S (MSTP)

BPDU protection, root protection and ring protection

Multicast

IGMP v1/v2/v3

IGMP Snooping

IGMP Fast Leave

Multicast group policy and multicast number limit

Multicast traffic cross VLAN duplication

IPv6

ICMPv6, DHCPv6, ACLv6, IPv6 Telnet

IPv6 Neighbor Discovery

Path MTU Discovery

MLD v1/v2

MLD Snooping

QoS

Traffic classification of each field of L2/L3/L4 protocol headers

CAR traffic control

802.1P/DSCP priority remark

Multiple queuing algorithms such as SP, WRR or SP+WRR

Tail-Drop, WRED

Traffic supervision and traffic shaping

Функции защиты

Identification and filtering of L2/L3/L4 based ACL

Defend against DOS or TCP attacks

Suppression of broadcast, multicast and unknown unicast packet

Port isolation

Port security, IP+MAC+port binding

DHCP Snooping, DHCP Option 82

IEEE 802.1x certification

Radius and BDTacacs+

Command line authority control based on user levels

Надежность

Static LACP link aggregation and cross service card link aggregation

EAPS, ERPS

ISSU

Обслуживание и управление

Console, Telnet, SSH 2.0

WEB based management style

SNMP v1/v2/v3

Upload and download of TFTP files

RMON
